pluto close up
© NASA/JHUAPL/SwRI
This high-resolution image captured by NASA's New Horizons spacecraft combines blue, red and infrared images taken by the Ralph/Multispectral Visual Imaging Camera (MVIC).
Pluto's famous "beating heart" of frozen nitrogen control its winds and may give rise to features on its surface, new research has found.

Uncovering how Pluto's atmosphere behaves has provided scientists with another place to compare our own planet with. Such findings can pinpoint both similar and distinctive features between Earth and a dwarf planet billions of kilometres away.

Pluto's heart-shaped structure, named Tombaugh Regio, quickly became famous after NASA's New Horizons mission captured footage of the dwarf planet in 2015 and revealed it is not the barren world scientists thought it was.

Nitrogen gas — an element also found in air on Earth — comprises most of Pluto's thin atmosphere, along with small amounts of carbon monoxide and the greenhouse gas methane.

Tombaugh Regio Pluto
© KP, NASA/APL/SwRI
Left: The heart-shaped region called Tombaugh Regio is outlined. This region is named after Pluto’s discoverer Clyde Tombaugh Right: False-colour images show compositional variations in Tombaugh Regio.
Frozen nitrogen also covers part of Pluto's surface in the shape of a heart. During the day, a thin layer of this nitrogen ice warms and turns into vapour. At night, the vapour condenses and once again forms ice. Each sequence is like a heartbeat, pumping nitrogen winds around the dwarf planet.

The new research, published in the Journal of Geophysical Research: Planets, suggests this cycle pushes Pluto's atmosphere to circulate in the opposite direction of its spin — a unique phenomenon called retro-rotation.

As air whips close to the surface, it transports heat, grains of ice, and haze particles to create dark wind streaks and plains across the north and northwestern regions.

"This highlights the fact that Pluto's atmosphere and winds — even if the density of the atmosphere is very low — can impact the surface," said Tanguy Bertrand, an astrophysicist and planetary scientist at NASA's Ames Research Center in California and the study's lead author.

Most of Pluto's nitrogen ice is confined to Tombaugh Regio. Its left "lobe" is a 1,000-kilometre ice sheet located in a three-kilometre deep basin named Sputnik Planitia — an area that holds most of the dwarf planet's nitrogen ice because of its low elevation.
nitrogen circulation Tombaugh Regio
© Glaciers return nitrogen ice from the eastern, upland, lobe of Tombaugh Regio through valleys into Sputnik Planitia on the west (context); red arrows show valley widths, blue arrows an apparent flow front on the planitia
Glaciers return nitrogen ice from the eastern, upland, lobe of Tombaugh Regio through valleys into Sputnik Planitia on the west (context); red arrows show valley widths, blue arrows an apparent flow front on the planitia
The heart's right "lobe" is comprised of highlands and nitrogen-rich glaciers that extend into the basin.

"Before New Horizons, everyone thought Pluto was going to be a netball — completely flat, almost no diversity," Bertrand said. "But it's completely different. It has a lot of different landscapes and we are trying to understand what's going on there."

Bertrand and his colleagues set out to determine how circulating air — which is 1,00,000 times thinner than that of Earth's — might shape features on the surface. The team pulled data from New Horizons' 2015 flyby to depict Pluto's topography and its blankets of nitrogen ice, and then simulated the nitrogen cycle with a weather forecast model and assessed how winds blew across the surface.
