Kuiper Belt
© Don Dixon/cosmographica.com
Just beyond Neptune is the Kuiper Belt, a torus of comet-like objects, which includes a few dwarf-planets like the Pluto-Charon dual-planet system. Despite being lumped together under one monicker, the Belt is composed of several different families of objects, which have quite different orbital properties.

Some are locked in place by the gravity of the big planets, mostly Neptune, while others are destined head in towards the Sun, while some show signs of being scattered into the vastness beyond. Patryk Lykawka is a one researcher who has puzzled over this dark, lonely region, and has tried to model exactly how it has become the way it is today.

Over the last two decades there has been a slow revolution in our understanding of how the Big Planets, the Gas Giants, formed. They almost certainly did not begin life in their present orbits - instead they migrated outwards from a formation region closer to the Sun. To do so millions of planetoids on near-misses with the Gas Giants tugged them gently outwards over millions of years.

We know what happened to the Gas Giants, but what of the planetoids? A fraction today form the Kuiper Belt and the Oort Cloud beyond it (how many Plutos exist out there?) But a mystery remains, which Lykawka convincingly solves in his latest monograph via an additional "Super-Planetoid", a planet between 0.3-0.7 Earth masses, now orbiting somewhere just beyond the Belt.

Such an object would be a sample of the objects that formed the Gas Giants, a so-called "Planetary Embryo". Based on the ice and silicate mix present in the moons of the Gas Giants, the object would probably be half ice, half silicates/metals, like a giant version of Ganymede. However such an object would also have gained a significant atmosphere, unlike smaller bodies, and being cast so far from the Sun, it would have retained it even if it was composed of the primordial hydrogen/helium mix of the Gas Giants themselves. This has two potentially very interesting consequences. David Stephenson, in 1998, speculated on interstellar planets with thick hydrogen atmospheres able to keep a liquid-water ocean warm from geophysical heat-sources alone. Work by Eric Gaidos and Raymond Pierrehumbert suggests hydrogen greenhouse planets are a viable option in any system once past about ~2.0 AU. A precondition that obtains for Lykawka's hypothetical Super Trans-Neptunian Object.

So instead of a giant Ganymede the object is more like Kainui, from Hal Clement's last novel, Noise. Kainui is a "hot Ganymede", a water planet with sufficiently low gravity that the global ocean hasn't been compressed into Ice VII in its very depths. Kainui's ocean is in a continual state of violent agitation, lethal to humans without special noise-proof suits, but Lykawka's Super-TNO would probably be wet beneath its dense atmosphere, warmed by a trickle of heat from its core and the distant Sun.

© Crowlspace
Gravitational perturbation studies of planetary orbits by Lorenzo Iorio constrain the orbital distance of such a body to roughly where Lykawka suggests it should be. A Mars-mass object (0.1 Earth-masses) would exist between 150-250 AU, while a 0.7 Earth-mass body would be between 250-450 AU. If we place it at ~300 AU, then its equilibrium temperature, based on sunlight alone, would be somewhere below 16 K. That's close to the triple-point of hydrogen (13.84 K @ 0.0704 bar), suggesting a frozen planet would result. However geophysical heat, from radioactive decay of potassium, uranium and thorium, could elevate the equilibrium temperature to over ~20.4 K, hydrogen's boiling point at 1 atm pressure. Thus a thick hydrogen atmosphere should stay gaseous.

To keep liquid water warm enough (~273 K) at the surface, the surface pressure will need to be ~1,000 bar, the equivalent of the bottom of Earth's oceans. An ammonia-water eutectic mixture would be liquid at ~100 bars and 176 K. With a higher rock fraction and higher radioactive isotope levels (as seen in comets, for example), liquid water might be possible at ~300 bars. Such a warm ocean would seem enticingly accessible since a variety of submarines and ROVs operate in the ocean at such pressures regularly. While the prospects for life seem dim, the variety of chemosynthetic life-styles amongst bacteria suggest we shouldn't be too hasty about dismissing the possibility.

A primordial atmosphere also invites thoughts of mining the helium for that rare isotope, helium-3. At 0.3 Earth masses and 1:3 ratio of ice to rock, such a body has 75% Earth's radius and just 40% the gravitational potential at its surface - even less at the top of the atmosphere. Such a planet would be incredibly straight-forward to mine and condensing helium-3 out of the mix would be made even easier by the ~30-40 K temperature at the 1 bar pressure level. There's no simple relationship between the size of a planet and its spin rate, but assuming Earth's early spin rate of 12 hours, then the synchronous orbital radius is just 2 Earth radii above the operating altitude of a mining platform. A space-elevator system would be straight-forward to implement, unlike the Gas Giants or even Earth.

Travelling to 300 AU is a non-trivial task, ten-times the distance to Neptune. A nuclear saltwater rocket, with an exhaust velocity of 4,725 km/s, could be used to accelerate to 3,000 km/s, then flip and brake at the destination. The trip would take ~six months.
